14
SERVICING
TYPE OF TYPE OF SINGLE - PHASE
HOT PLATE CABLE POWER SUPPLY
CABLE TYPES AND SECTIONS
ATTENTION!!!
If the power supply cable is replaced, the installer should leave the ground wire longer than the phase
conductors (fig. 19) and comply with the recommendations given in paragraph 6.
FIG. 19
H05 RR - F Section 3 X 0.75 mm
2
Gas hot plate
