Baumatic BR26A - Decor Door Installation

23
Fitting the Décor Door -
2
) Fix the slide guides
(attached in a plastic
bag along with the
screws ST 4.2 x 9.5) to
the edge of the door.
Cover the open holes
with the attached caps.
3
) Hold the appliance
door to the décor door
(See Fig. 2, at left).
4) Insert the slides into the
guides and fix them on
the kitchen unit door
some 15mm from the
edge, using the A 4 x 12
screws (Fig. 3, at right).
5) Remove the slide guides
and separate the
appliance door from the
door of the kitchen unit.
1) Using a 3mm diameter bit,
make holes sufficient to
attach the hinge rail brackets
as shown in Fig. 2 on next
pag
e.
INSTALLING YOUR BR26 FRIDGE-FREEZER
