Baumatic BT2740SS - Using the Hob Top; Electric Ignition

Using the hob top
The following symbols will appear on the control panel, next to each
control knob:
Black circle: gas off
Large flame: maximum setting
Small flame: minimum setting
o The minimum setting is at the end of the anti-clockwise rotation
of the control knob.
o All operation positions must be selected between the maximum
and minimum positions.
o Never select a knob position between the maximum and off
position.
Electric ignition
To ignite a burner:
o Press in the control knob of the burner that you wish to light and
turn it anti-clockwise to the spark symbol which is just after the
maximum position.
o Whilst keeping the control knob depressed, press the hob
ignition button and the burner will light. Keep the hob ignition
button pressed down until the burner is fully lit.
o In case of power failure, the burners can be lit by carefully using
a match.
18
