Mounting
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09
57
of 142
6
Figure 21: Mounting instruction BM4163-S
Device BM4163-S
A - screws 4 x M8
B - washers 4 x (8,4 x 17)
c - mounting space c = 0,7 mm
