SYSTEM. Steering.
New VISION 46
42
Steering System:
Twin Wheel Single Rudder Open Wire Steering
Following the principle of one continuous 7x19 stainless steel
cable starting and ending at the radial quadrant on the rudder
stock.
Emergency tiller is applied through the lid covered access from
the cockpit floor.
Emergency tiller is stowed in the aft storage kept at the
bulkhead.
Rudder Bearings:
The bearings of the rudder stock are self aligning, roller bearing
type units.
Autopilot Drive (optional):
Rotary Sprocket Drive fitted to the port side idler bracket
running on a separate continuous chain loop to the port side
steerer.
(Emergency Tiller drawn right below)
