Nortel/Avaya E&M Trunk Cartridge Wiring Chart
For 568B
SLOT 1 PORT 1 LANE 1 SLOT 1 PORT 2 LANE 2
FROM E&M Service To RJ45 Jack FROM E&M Service To RJ45 Jack
White-Blue T White-Blue White-Slate T White-Blue
Blue-White R Blue Slate-White R Blue
White-Orange T1 White-Orange Red-Blue T1 White-Orange
Orange-White R1 Orange Blue-Red R1 Orange
White-Green E White-Green Red-Orange E White-Green
Green-White SG Green Orange-Red SG Green
White-Brown M White-Brown Red-Green M White-Brown
Brown-White SB Brown Green-Red SB Brown
SLOT 2 PORT 3 LANE 1 SLOT 2 PORT 4 LANE 2
FROM E&M Service To RJ45 Jack FROM E&M Service To RJ45 Jack
Red-Brown T White-Blue Black-Green T White-Blue
Brown-Red R Blue Green-Black R Blue
Red-Slate T1 White-Orange Black-Brown T1 White-Orange
Slate-Red R1 Orange Brown-Black R1 Orange
Black-Blue E White-Green Black-Slate E White-Green
Blue-Black SG Green Slate-Black SG Green
Black-Orange M White-Brown Yellow-Blue M White-Brown
Orange-Black SB Brown Blue-Yellow SB Brown
SLOT 3 PORT 5 LANE 1 SLOT 3 PORT 6 LANE 2
FROM E&M Service To RJ45 Jack FROM E&M Service To RJ45 Jack
Yellow-Orange T White-Blue Violet-Blue T White-Blue
Orange-Yellow R Blue Blue-Violet R Blue
Yellow-Green T1 White-Orange Violet-Orange T1 White-Orange
Green-Yellow R1 Orange Orange-Violet R1 Orange
Yellow-Brown E White-Green Violet-Green E White-Green
Brown-Yellow SG Green Green-Violet SG Green
Yellow-Slate M White-Brown Violet-Brown M White-Brown
Slate-Yellow SB Brown Brown-Violet SB Brown
