1.0 Quick Reference Guide
3
© Baxi Heating UK Ltd 2013
R
R
DHW and CH OFF (frost protection still enabled)
Indicate errors that prevent burner from starting
Error - Not resettable by user
Water pressure too low
Indicates a resettable error
Indicates navigation in programming mode (parameter)
Indicates navigation in programming mode
Generic error
Burner lit
DHW request
Heating mode
Units for temperature
Units for pressure
Service due
Display Description
Central Heating (CH)
Temperature Adjustment
Boiler Information View Standby - Reset - Esc
R
Key to Controls
Display showing all available segment
Summer - Winter - Only Heating
Mode
Domestic Hot Water (DHW)
Temperature Adjustment
Summer - DHW only request mode
Winter - DHW & CH request mode
Only Heating - Only CH request mode
NOTE: When altering any settings it is necessary that
the buttons are FIRMLY pressed for several seconds.
Standby - Reset - Esc
Boiler Information View
Increase CH Temperature Button *
Decrease CH Temperature Button *
* Important Note: If your control system is fitted
with the Optional Outdoor Sensor, these buttons
will affect it’s operation. Please consult your
installer for advice.
Increase DHW Temperature Button
Decrease DHW Temperature Button
Summer / Winter / Only Heating Mode Button
To Next Page
