Bay-Tek SMOKIN TOKEN User Manual (English)

Questions and Answers:

T
traci21Aug 18, 2025
How to troubleshoot no power to my Bay-Tek Game?
- K
  Kurt BookerAug 18, 2025
  If your Bay-Tek Game has no power, start by checking the wall outlet to ensure it's plugged in. Then, verify the power strip breaker switch or the building circuit breaker hasn't tripped and reset it if necessary. Also, make sure the unit is properly plugged into the power strip. If these steps don't restore power, the power supply might be faulty, and you should refer to the power supply diagnostic for further troubleshooting.
F
fostermelvinAug 21, 2025
What to do if there is no audio on my Bay-Tek Game?
- C
  Crystal BrownAug 21, 2025
  If there is no audio on your Bay-Tek Game, first increase the volume using the volume control located inside the front door panel. If that doesn't work, check the audio cable connections to the speaker, volume control, and main circuit board for any loose wires; also check continuity. If the problem persists, the potentiometer might be defective and need replacement (A5PO1K). As a last resort, the main circuit board might be malfunctioning; try replacing it with a board from another Gen 5 game to confirm if this is the issue.
M
marissabartonAug 23, 2025
Why aren't tickets dispensing correctly on my Bay-Tek SMOKIN TOKEN Game?
- E
  Elizabeth Wright MDAug 23, 2025
  If tickets are not dispensing correctly from your Bay-Tek Game, start by checking all connectors for disconnected, loose, or broken wires and verify continuity. Next, inspect the opto sensor on the ticket dispenser for dust; blow it off and clean with isopropyl alcohol. If the issue continues, try replacing the ticket dispenser with a working one to see if that resolves the problem. Also, ensure that the notch on the tickets isn't cut too shallow; if so, flip the tickets and load them upside down so the large cut notch faces the opto sensor.
K
Kayla SuarezAug 26, 2025
How to fix fluorescent lighting that is not functioning properly in my Bay-Tek Game?
- F
  faustinAug 26, 2025
  If the fluorescent lighting in your Bay-Tek Game isn't working right, first ensure the fixture is plugged into the power strip. If the lamp is out, replace the burned fluorescent tube. If neither of those steps works, the entire fixture may be faulty and need replacement.
C
Christine ContrerasAug 28, 2025
What to do if my Bay-Tek SMOKIN TOKEN Game doesn’t score?
- I
  Isabella BrennanAug 28, 2025
  If your Bay-Tek Game isn’t scoring, and you hear no 'Yippee Yahoo' sound when a coin is dropped, the switch in the coin mechanism might be bad, requiring replacement (AASW2700). Also, check the connectors for disconnected, loose, or broken wires and verify continuity. If there are no game sounds at all, refer to the No Audio section to restore sound.
L
Laura NicholsonAug 30, 2025
How to troubleshoot upper displays not functioning properly on Bay-Tek Game?
- D
  Danielle BooneAug 30, 2025
  If the upper displays on your Bay-Tek Game aren't functioning correctly, check the cable connection to the main board and verify continuity. Consider replacing the white (or grey) cable. If the issue persists, the circuit board may be faulty and need replacement with tickets owed board (AABD2603).
J
Jonathan McmillanSep 1, 2025
What causes the wheel not to rotate on my Bay-Tek SMOKIN TOKEN Game?
- R
  rogersmarySep 1, 2025
  If the wheel isn't rotating on your Bay-Tek Game, first reconnect the motor wiring. Then, check for loose or broken wiring at the connectors for the motor and main circuit board, verifying continuity from the plug to the crimped ends. If the issue persists, the motor may be faulty and need replacement (AAMO2700).
C
Crystal GrahamSep 3, 2025
Why is the upper backlighting not functioning properly on my Bay-Tek SMOKIN TOKEN?
- S
  Shelby ShepardSep 4, 2025
  If the upper backlighting on your Bay-Tek Game isn't working correctly, start by checking the cable for a proper connection to the main board and verifying continuity. Replace the grey cable if necessary. If the lamps are out, replace the burned-out lamps. If the issue continues, the lamp circuit board may be faulty and need replacement with board AABD2705.
T
Tyler CarlsonSep 6, 2025
What does Err. 3 Wheel Speed Fault mean on my Bay-Tek SMOKIN TOKEN Game?
- J
  Jessica ParkSep 6, 2025
  If your Bay-Tek Game displays 'Err. 3 Wheel Speed Fault', first check that the setscrew on the wheel hub is tight. If that doesn't solve the issue, the wheel motor might be faulty and need replacement. Also, ensure the score wheel isn't too far away or too close to the Wheel Position Sensor; reposition the wheel on the motor shaft so the silver dots are about 3/8 inch away from the sensor. Finally, the Wheel Position Sensor board might not be reading any silver dots, in which case you should clean or replace the Wheel Position Sensor (AASE2700) and consider replacing the silver dot board (A5BD2701).
J
Julie GonzalezSep 8, 2025
Why is the Tickets Owed Display not adding correctly on my Bay-Tek SMOKIN TOKEN Game?
- S
  savagemasonSep 8, 2025
  If the Tickets Owed Display on your Bay-Tek Game isn't adding correctly, first check the dipswitch settings on the main Gen 5 board to ensure they are correct. Also, consider that the game might be scoring too soon, before the coin reaches the Slot sensor board; in that case, the Slot sensor board may be bad, requiring you to align or clean the sensors, replace the chip, or replace the board.
