Bay 5 - Stove Dimensions - Bay 5 VL; Bay 5 VL Dimensions and Views

®
Bay 5VL (mm)
charnwood
BAY
FRONT VIEW
BACK VIEW
SIDE VIEW
Note: Door extends a maximum of 573mm
from front of stove when open.
PLAN VIEW
685
474
73
347
234
118
(for a 6" flue)
155
70
100
85
412
610
20
