Bay 5 - Stove Dimensions - Bay 5; Bay 5 Dimensions and Views

®
Bay 5 DIMENSIONS (mm)
20
685
495
610
235
350
120
85
70
ø100
ø155
412
70
FRONT VIEW BACK VIEW
SIDE VIEW
Note: Door extends a maximum of 573mm
from front of stove when open.
PLAN VIEW
(for a 6" flue)
350
FRONT VIEW WITH FIREPLACE TRIM
599
charnwood
BAY
