Bayliner Capri - 1750 CH, 1950 CL,1952 CN, 1954 CW, 2150 CT and 2152 CY

Chapter 3: Components & Systems 31
Capri Runabouts • Owner’s Manual Supplement
1750CH, 1950CL,1952CN, 1954CW, 2150CT and 2152CY.
The following is the procedure for converting the jump seats into a sunlounge for
the Capri 1750CH, 1950CL, 1952CN, 1954CW, 2150CT and 2152CY.
B
C
STEP - 2
A
Step - 2:
Slide the lounge support inserts
(B) into the lounge support
slots (C).
STEP - 3
MOTOR BOX
A
STEP - 1
AC C
Step - 1:
Remove the jump
seats (A) by sliding
them forward.
Step - 3:
Press down firmly on
the inboard side of
each jumpseat until
they rest firmly on
the motorbox ledge.
