GAIN CONTROL
Input gain control.
MID EQ FREQUENCY SELECTOR
Continuously variable from 400Hz to 2.5kHz.
TREBLE CONTROL
12 dB of boost or cut at 10kHz.
CLIP INDICATOR
Indicates input over-
load. There is 3dB of
headroom left when
this is illuminated.
1/4” OUTPUT
The 1/4” output is designed
for running instrument
cables directly into the next
instrument level input of
your signal chain.
BASS CONTROL
12 dB of boost or cut at 60Hz.
CONTROLS AND CONNECTORS
3
MID EQ LEVEL CONTROL
12 dB of boost or cut at the
selected frequency.
MUTE INDICATOR
LED illuminates when
mute footswitch is
engaged.
MUTE FOOT SWITCH
Engages mute function.
When engaged, signal passes
to the tuner output only.
