BATTERY REPLACEMENT
BATTERY COMPARTMENT
Pull the latch to the left with
thumbnail to release the hinged
battery compartment cover.
Carefully unplug battery without
straining cables. Replace with
fresh battery in reverse order.
Use a standard 9Volt battery.
Battery life is about 15 hours.
Unplugging the input to the
Sonic Stomp will turn the unit off
and conserve battery life.
POWER SUPPLY
CONNECTOR
Connect the 9VDC
power supply here.
4
