EXPLODED DIAGRAM & PARTS LIST
NO SKU DESCRIPTION QTY
1 SP-PHD-71CC-001 GAS ENGINE, 71CC 1
2 SP-PHD-71CC-002 HANDLEBAR ASSEMBLY 1
3 SP-PHD-71CC-003 TRANSMISSION COMPLETE 1
4 SP-PHD-71CC-004 TRIGGER ASSEMBLY 1
5 SP-PHD-71CC-005 BOLT PPH 10-24×16 1
6 SP-PHD-71CC-006 THROTTLE CABLE 1
7 SP-PHD-71CC-007 BOLT HH 1/4"-20×19 4
8 SP-PHD-71CC-008 GEAR CASE TOP 1
9 SP-PHD-71CC-009 CLUTCH DRUM 1
10 SP-PHD-71CC-010 BALL BEARING DOUBLE LIP R12-2RS 3
11 SP- PHD-71CC- 011 GEAR 7T PINION THREADED 1
12 SP-PHD-71CC-012 SNAP RING Φ19 2
13 SP-PHD -71CC-013 DOWEL PIN STEEL 1
14 SP-PHD-71CC-014 GEAR 44T 1
15 SP-PHD-71CC-015 GASKET 1
NO SKU DESCRIPTION QTY
16 SP-PHD-71CC-016 BALL BEARING R10 2
17 SP- PHD-71CC- 017.2 GEAR 48T 1
17 SP- PHD-71CC- 017.3 GEAR 10T 1
18 SP-PHD-71CC-018 GEAR CASE BOTTOM 1
19 SP-PHD-71CC-019 SHAFT OUTPUT 7/8" 1
20 SP-PHD-71CC-020 BOLT HEX SKT HD 1/4"-20×38 2
21 SP-PHD-71CC-021 BOLT HEX SKT HD 1/4"-20×50 4
22 SP-PHD-71CC-022 EARTH AUGER 10" 1
23 SP-PHD-71CC-023 BOLT HEX SKT HD M8×50 1
24 SP-PHD-71CC-024 NUT HEX NYLOC M8 1
25 SP-PHD-71CC-025 BOLT HEX SKT BUTTON HD M6×18 4
26 SP-PHD-71CC-026 NUT HEX FLANGE LOCK M6 4
27 SP-PHD-71CC-027 EARTH BLADE 10" (SR) 2
28 SP-PHD-71CC-028 FISHTAIL POINT SHARPENED 1
SKU DESCRIPTION QTY
SP-PHD -71CC- 001.1 CRANKCASE AND CYLINDER BLOCK 1
SP-PHD-71CC-002.1 SPARK PLUG 1
SP-PHD -71CC- 003.1 VALVE, COMPRESSION RELEASE 1
SP-PHD -71CC- 004.1 HALFMOON KEY, FLYWHEEL 3×5.9×13 1
SP-PHD-71CC-005.1 FLY W HEEL, MAGNE TO 1
SP-PHD -71CC- 006.1 NUT HEX FLANGE M8 1
SP-PHD-71CC-007.1 WASHER ¬8.4×16×1.5 2
SP-PHD -71CC- 008.1 CLUTCH ROTOR ASSEMBLY W/SPRING 1
SP-PHD -71CC- 009.1 WASHER, WAVE ¬10 2
SP-PHD-71CC-010.1 BOLT, SHOULDER 8×24 2
SP- PHD-71CC- 011.1 PIN, LOCATING ¬5×12.5 2
SP-PHD-71CC-012.1 MOUNT RING & SHROUD 1
SP-PHD -71CC- 013.1 BOLT W/WASHER HEX SKT HD M5×28 4
SP-PHD-71CC-014.1 IGNITION COIL 1
SP-PHD -71CC- 015.1 BOLT HEX SKT HD M4×20 2
SP-PHD -71CC- 016.1 WASHER, PLATE 4 2
SP- PHD-71CC- 017.1 WINDPIPE, INTAKE 1
SP-PHD -71CC- 018 .1 GASKET, INTAKE 1
SP-PHD -71CC- 019.1 BOLT W/WASHER HEX SKT HD M5×32 1
SP-PHD-71CC-020.1 BOLT W/WASHER HEX SKT HD M5×22 1
SP-PHD -71CC- 021.1 GASKET, CARBURETTOR 1
SP-PHD-71CC-022.1 CARBURETTOR ASSEMBLY 1
SP-PHD -71CC- 023.1 AIR FILTER ASSEMBLY 1
SP-PHD-71CC-024.1 BOLT W/ WASHER PPH M5×52 2
SP-PHD -71CC- 025.1 PLATE, REINFORCEMENT 1
SP-PHD -71CC- 026.1 FOAM, AIR FILTER 1
SP-PHD-71CC-027.1 COVER, AIR FILTER 1
SKU DESCRIPTION QTY
SP-PHD-71CC-028.1 GASKET, EXHAUST 1
SP-PHD -71CC- 029.1 WINDPIPE, EXHAUST 1
SP-PHD -71CC- 030.1 MUFFLER ASSEMBLY 1
SP-PHD -71CC- 031.1 BOLT W/WASHER PPH M5×12 2
SP-PHD -71CC- 031.1 WASHER, FL AT, 5 2
SP-PHD-71CC-033.1 BOLT HEX SKT HD M5×65 2
SP-PHD -71CC-34.1 COVER, MUFFLER 1
SP-PHD -71CC- 035.1 BOLT W/WASHER HEX SKT HD M5×12 1
SP-PHD -71CC- 036.1 RECOIL CLUTCH 1
SP- PHD-71CC- 037.1 PL ATE, RECOIL 1
SP-PHD -71CC- 038.1 RECOIL ASSEMBLY 1
SP-PHD -71CC- 039.1 BOLT W/WASHER HEX SKT HD M5×20 3
SP-PHD -71CC- 040.1 BOLT W/WASHER HEX SKT HD M5×25 1
SP-PHD -71CC- 041.1 SHROUD, ENGINE 1
SP-PHD-71CC-042.1 COVER, ENGINE SHROUD 1
SP-PHD -71CC- 043.1 BOLT W/WASHER PPH M5×16 1
SP-PHD -71CC- 044.1 BRACKET LOWER, GAS TANK 1
SP-PHD-71CC-045.1 BRACKET UPPER, GAS TANK 1
SP-PHD -71CC- 046.1 GAS TANK 1
SP- PHD-71CC- 0 47.1 FUEL LINE KIT ASSEMBLY 1
SP-PHD -71CC- 048.1 GAS CAP ASSEMBLY 1
SP-PHD -71CC- 049.1 CUSHION, RUBBER 2
SP-PHD-71CC-050.1 BOLT HEX FLANGE M5×18 4
SP-PHD-71CC-051.1 SHROUD, GAS TANK 1
SP-PHD-71CC-052.1 GASKET, MUFFLER 1
SP-PHD-71CC-053.1 SWITCH, ROCKER 1
