BCP SKY1643 - Mounting Procedures; Mounting to the Wall

Pg. 5
• Position the part 5 top bracket on the wall and mark where the four screw holes will be. Make sure that
the bracket is level.
• Use an electric drill to drill the screw holes.
Screw four part 4 wall anchors into holes,
then attach the part 5 top bracket to the
wall with four part 1 screws.
Attach the part 6 bottom bracket to
the bottom of the part A fireplace with
two part 2 screws.
WALL
TOOLS REQUIREDMOUNTING TO THE WALL
1
2
5
4
1
A
2
6
