BCP SKY1733 - Step 5: Seat and Bellows Installation

Pg. 5
Remove hardware from the part N seat and use the same hardware to attach the seat to the part O seat
tube. Then, slide the part A bellow onto the seat tube and slide the assembled seat onto the main frame.
Use a part 7 tri-knob to secure it in place.
Install part 8, 9, and 10 nut caps in the appropriate locations.
8
9
10
N
O
A
5
7
10
8
