Pg. 6
Slide on a part B back wheel. Compress the button behind the wheel while inserting and it will lock in place.
Pull on the wheel to make sure it is secure. Repeat on the other side to install the other back wheel.
Remove the bolt on the rear wheel axle of your bike. Place the coupling piece on the end of the towing bar
between the bolt and bike frame, then replace the bolt to secure it in place. Wrap the safety strap around
the frame for added security.
Quick release: Unclip and remove the metal pin from the end of the towing bar to remove the coupling
piece. Leave the coupling piece on your bike so you can easily attach and remove the trailer.
4
TRAILER ASSEMBLY
5
B B
To Next Page
