BCP SKY2567 - Step 3: Attaching Panels to Bottom Frame; Step 4: Securing Frame to Bottom Frame

Pg. 6
PRODUCT ASSEMBLY
3
4
Attach part G front panel, part I side panels, and part H rear panel to part A bottom frame using two part
1 B pins for each panel.
Attach the completed item from step 1 to part A bottom frame using six part 3 bolts, six part 5 nuts, and
six part 9 washers.
Attach the completed item from steps 2 to part A bottom frame using four part 3 bolts, four part 5 nuts,
and four part 9 washers.
x2
I
H
G
A
x8
1
x10
x10
x10
9
5
3
