BCP SKY3043 - Page 5

| 5
PRODUCT ASSEMBLY
3
4
Attach the assembled support to the legs with six part 1 bolt sets. Place twelve part 6 end caps
on the exposed nuts, two end caps per bolt set.
Attach two part F bench legs to a part B bench with four part 2 bolt sets. Place four part 7 end
caps on the exposed nuts.
B
F
2
6
1
x12
x6
7
x4
x2
x4
