PRODUCT ASSEMBLY
2
8 |
Within the seat, join the connectors from the gear boxes to the corresponding connectors.
Insert the red wire into the red terminal on one of the batteries.
Attach two part E motor hoods with eight part 1 screws, four screws per motor hood.
Position motor hoods so the
tracks face the inside & wires
route through the tracks.
x2
E
x8
1
CHARGING PORT
To Next Page
