4
PRODUCT ASSEMBLY
3
Remove two nuts from the bottom of the part D front axle. Remove the nut on the steering column.
Insert the front axle and two part 1 springs into the front frame. Insert the steering column
into the designated hole on the front axle. Replace the nuts on the front axle/steering
column to secure it in place.
Slide a part B wheel onto the rear axle and secure it by replacing a nut/washer. Snap on a
part C cap. Repeat on the other side.
NOTE: Use two plastic wrenches (one on each side) and rotate in opposite directions
to tighten nuts.
B
C
x2
x2
| 9
