K
J
I
H
6
10 |
PRODUCT ASSEMBLY
8
Remove the adjustment bolt and washer from the part I adjustment bar. Place the washer on
the part J saddle post, then slide the adjustment bar into the saddle post and secure with the
previously removed adjustment bolt.
Locate the part H seat and remove the three nylon nuts and washers on the bottom. Place the
seat onto the adjustment bar and reattach the three nuts and washers.
Slide the part K decorative sleeve over the saddle post and insert the saddle post into the part
A main frame. Set the seat to a comfortable height, then secure with the part 6 tri-knob.
