| 7
PRODUCT ASSEMBLY
4
Attach the part F and G pedals with four part 8 bolts and nut sets.
Attach the four part 7 end caps as indicated.
Insert the part L left handlebar into the part D left frame bar. Select a comfortable height and
secure with the adjustment knob.
Repeat to attach the part M right handlebar, then cover each knob with one part 3 nut cap.
3
x2
L
M
5
G
7
x4
F
8
x4
To Next Page
