BCP SKY6138 - Page 8

8 |
PRODUCT ASSEMBLY
6
Connect the wires on the main frame and the part N computer post, then insert the computer
post into the main frame and secure with two part 9 adjustment knobs.
Remove the two screws from the part N computer post, then use the screws to attach the part
P bottle holder to the part N computer post.
N
9
x2
P
