PRODUCT ASSEMBLY
2
Attach two part H pole braces to the part Y bottom pole with one part E bolt and nut set.
Attach the part H pole braces to the part O base with two part C bolt and nut sets. Set this
assembly aside, upright.
H
x2
E
3
Y
O
A
I
x2
B
x2
C
x2
