PRODUCT ASSEMBLY
5
Attach the part M net to the part L rim as shown:
M
L
6
Insert the part X middle pole into the part Y bottom pole, then secure with one part F bolt and
nut set.
Insert the part W top pole into the part X middle pole, then secure with one part F bolt and
nut set and one part G knob.
NOTE: This will assemble pole at regulation height: 2.3m – 3.05m
W
X
Y
