BCS MAX 615 L - Page 31

29
TABELLA 1 – TABLE 1 – TABLEAU 1 – TABLA 1 – TAFEL 1
PB H
MACCHINA
MACHINE
MACHINE
MAQUINA
MASCHINE
P = 3.50 – 8
D = 395 mm (15,5”)
L = 97 mm (3,8”)
bar = 1,2 / 1,5
P = 4.00 – 8
D = 427 mm (17”)
L = 108 mm (4,3”)
H = 10 kg (lbs 22)
bar = 1,2 / 1,5
P = 4.0 – 10
D1 = 455 mm
L1 = 135 mm
D = 463 mm (18”)
L = 114 mm (4,5”)
H = 15 kg (lbs 33)
bar = 1,2 / 1,5
P = 5.0 – 10
D1 = 500 mm
L1 = 135 mm
D = 512 mm (20”)
L = 140 mm (5,5”)
H = 15 kg (lbs 33)
bar = 1,2 / 1,5
P = 21x11.00 – 8
D = 518 mm
L = 280 mm
bar = 0,5 / 0,6
P = 16x6.50 – 8
D = 405 mm
L = 165 mm
bar = 1,2 / 1,5
615
615 L
615 SL
S = 425 mm S = 435 mm S = 566 mm
620
S = 435 mm
S = 467 mm
M = 539 mm
630 / BM8
S = 477 mm
M = 549 mm
S = 503 mm
M = 575 mm
S = 783 mm
