38
B OPERATING INSTRUCTIONS
Step 3: Connect the communication cable to the upper end of the right front support, place the handrail frame (24) on top
and secure it with 4x M8×15 Allen screws (104).
104
104
104
104
62
63
24
Step 4: Connect the signal cables of the console. Now insert the console into the handrail bracket (24) and secure it with 4x
M6×10 screws (103).
103
24
72
