INSTALLING THE ISOFIX AND SUPPORT
LEG
Installation of ISOFIX Base System
see images 4-13:
4. Unfold the load leg from storage compartment.
4. 1-Insert the rebound bar downwards until you hear
a “click” which means that the assembly is complete.
5. 1-If required attach the plastic guides onto the
vehicle ISOFIX bars.
6. 1-Extend the ISOFIX connectors by pulling release
strap.
6. 2-Press the ISOFIX adjuster button 6. -1 and push
to adjust 7. untill rebound bar tight against the vehicle
seat.
7. 1-Make sure that both ISOFIX connectors are secu-
rely attached to their ISOFIX anchor points. The colors
of the indicators on both ISOFIX connectors should be
completely green.
! There are 9 adjustable positions for ISOFIX. Press the
ISOFIX release button and push the base back against
the vehicle seat until tight.
8-9. After placing the base on the vehicle seat,
extend the load leg to oor 8. -1, when the load leg
indicator shows green means it is installed correctly.
! When the load leg indicator shows red this means
the load leg is in the wrong position.
! Make sure the load leg is in full contact with the
vehicle oor pan.
! Squeeze the load leg releasing button, then shorten
the load leg upwards. 8.
10. 1-! The ISOFIX connectors must be attached and
