the child needs to sleep you should put him in a
suitable carrycot, cot or bed.
INSTRUCTIONS FOR ASSEMBLY AND USE
OPENING THE CHASSIS
A:Open the catch as the arrow direction.
B:Hold the handlebar with one hand, and hold the front
tube with another hand, then open the chasis as the arrows
direction until “click” sound.
ASSEMBLING THE FRONT WHEELS
A:Connect the front wheel to the connect pieces as the arrow
direction.
B:To close the swivel-function: lift up the swivel lock button.
C:To release the front wheel: press the button on the connec-
tor pieces.
ASSEMBLING THE REAR WHEELS
A:Connect the rear wheels as the arrow direction.
B:To release the rear wheels: pull out the metal button and
remove the rear wheels as the arrow direction.
APPLYING THE BRAKES
A:To engage the brakes: step down the brake pedal.
B:To release the brakes: lift up the brake pedal with your foot.
FITTING AND REMOVING THE HAMMOCK
Your QUANTUM is tted with the pro-x system. With this sys-
tem, the hammock can be attached perfectly to the chassis.
To take the hammock off, simultaneously pull the unlocking
levers situated on both sides of the hammock (5.1 - 5.2). The
hammock is reversible so it can be positioned facing you or
facing forwards
ADJUSTING THE HANDLEBAR HEIGHT
A:Press the buttons of bothside and pull the handlebar
upwarkds or downwards.
FOLDING THE PUSHCHAIR
A:Furl the canopy as the arrow direction.
B:Press down the 2nd safety button and pull upwards the
folding triggers on the backside of side bars. then press down
the handlebar until the pushchair is folded
C:The folding carth will work.
ATTENTION: THE PUSHCHAIR COULDN’T BE FOLDED WHEN
THE HAMMOCK IS FACING THE PUSHER AND THE HAMMOCK
IS ON THE UPRIGHT POSITION!
OPENING THE PUSHCHAIR
A:Release the folding catch as the arrow direction and lift up
the handlebar with your two hands until “click” sound.
PRO-FIX SYSTEM
1.
2.
6.
7.
8.
3.
4.
5.
