9.2 Generator won’t produce power
· Safety device (DC protector) to “OFF”…. Press the DC protector to
“ON”.
· The AC pilot light (Green) goes off …. Stop the engine, then restart.
10. SPECIFICATIONS
Item I3000R Generator
Generator
Type Silent Inverter
Rated frequency (Hz) 60
Rated voltage (v) 120
Rated output power (kW) 2.8
Max output power (kW) 3
Power Factor 1
Charging Voltage (DC)(V) 12
Charging Current (DC)(A) 8.3
Overload Protect (DC) Non-fuse
Protector
Phase Single
Engine
Engine R210
Engine type Single cylinder,
4-stroke, forced air
cooling, OHV
Displacement (cc) 212
Fuel type Unleaded Gasoline
Fuel tank capacity (L) 9
Fuel Consumption (g/
(kW·h)
395
Continue Running Time (at
rated power)(h)
5
Oil Capacity (L) 0.5
Spark Model No. F6RTC
Starting mode Recoil Starter
Generator
set
Length x Width x Height
(mm)
605 x 432 x 493
Net weight (kg) 37
11. WIRING DIAGRAM
SPECIFICATIONS WIRING DIAGRAM
