Beam 17R - Main Control - Settings; Pan;Tilt Inversion and Swap; Encoder and Signal Behavior; Display, Lamp, and Color Settings

This function allows you to invert the Pan via display command. Press Ok use the ▲ or ▼ to select Pan rotation configuration. Press OK to
confirm the setting .
Invert Pan
This function allows you to invert the Tilt via display command. Press Ok use the ▲ or ▼ to select Tilt rotation configuration. Press Ok to
confirm the setting .
Invert Tilt
This function will Swap the Pan Tilt channel on DMX control via display command. Press Ok use the ▲ or ▼ to select Swap the DMC channels
for the Pan & Tilt Press Ok to confirm the setting .
CH 1&2 Pan CH 3&4 Tilt =OFF
CH 1&2 Tilt CH 3&4 Pan =ON
Swap Pan-Tilt
This function will allow you to enable or disable the encoders for the Pan and Tilt. Press Ok use the ▲ or ▼ to select ON or OFF Press Ok to
confirm the setting .
(note) encoders are electronics that will reposition the unit if it’s manually moved.
Encoder Pan-Tilt
If DMX signal is removed or terminated the fixture will keep the last command or it will clear the command and place the fixture at 0 on all
channels. Press Ok use the ▲ or ▼ to select KEEP or CLEAR Press Ok to confirm the setting .
No DMX Signal
This command will allow you to select to leave the display permanently on when the fixture is on, or it will let you turn off the display after 30
seconds of not pressing the buttons. Press Ok use the ▲ or ▼ to select OFF or ON Press Ok to confirm the setting .
Display Power Save
Run Mode
DMX Address
Channel Mode
Demo Mode
Invert Tilt
Swap Pan-Tilt
Encoder Pan-Tilt
No DMX Signal
Display
DMX
001
16CH
1
OFF
OFF
ON
KEEP
OFF
Run Mode
DMX Address
Channel Mode
Demo Mode
Invert Tilt
Swap Pan-Tilt
Encoder Pan-Tilt
No DMX Signal
Display
DMX
001
16CH
1
OFF
OFF
ON
KEEP
OFF
Run Mode
DMX Address
Channel Mode
Demo Mode
Invert Tilt
Swap Pan-Tilt
Encoder Pan-Tilt
No DMX Signal
Display
DMX
001
16CH
1
OFF
OFF
ON
KEEP
OFF
Run Mode
DMX Address
Channel Mode
Demo Mode
Invert Tilt
Swap Pan-Tilt
Encoder Pan-Tilt
No DMX Signal
Display
DMX
001
16CH
1
OFF
OFF
ON
KEEP
OFF
Run Mode
DMX Address
Channel Mode
Demo Mode
Invert Tilt
Swap Pan-Tilt
Encoder Pan-Tilt
No DMX Signal
Display
DMX
001
16CH
1
OFF
OFF
ON
KEEP
OFF
Run Mode
DMX Address
Channel Mode
Demo Mode
Invert Tilt
Swap Pan-Tilt
Encoder Pan-Tilt
No DMX Signal
Display
DMX
001
16CH
1
OFF
OFF
ON
KEEP
OFF
This command will allow you to select whether the lamp will turn on after it receives power or to turn on the lamp only when it receives a DMX
command to do so. Press Ok use the ▲ or ▼ to select OFF or ON Press Ok to confirm the setting .
Lamp On @ Starting
Lamp on@Starting
Linear Color
Load Default
ON
OFF
►
This function will allow you to select whether the colors wheel will snap into color and bi-color or a continues control over any position of the
color wheel. Press Ok use the ▲ or ▼ to select OFF or ON Press Ok to confirm the setting .
Linear Color
Lamp on@Starting
Linear Color
Load Default
ON
OFF
►
This command will change the display command back to original factory settings. Press Ok then press Ok again to load to factory settings use
the ▲ or ▼ to cancel.
Load Default
Lamp on@Starting
Linear Color
Load Default
ON
OFF
►
7
