ASSEMBLY / OPERATING INSTRUCTIONS
To assemble Cot continued...
4
5
6
7
8
Slide the Mattress Base between the End Panels.
Secure the Mattress Base using 4 x 35mm bolts.
Do not tighten completely.
Attach the remaining Side Panel between the
End Panels using 4 x 60mm bolts.
Tighten all bolts until firm.
Do not over tighten bolts. Over tightening bolts
can cause panels to crack.
Rotate Cot so it is upside down on the floor.
4a.
5a.
5b.
6a.
7a.
8a.
MATTRESS BASE ‘THIS SIDE UP’ LABEL MUST BE FACING UPWARD WHEN
MATTRESS BASE IS INSTALLED
WARNING
