Assembly / Operating Instructions
1. Hold both straps whilst pushing in the
button of the seat adjuster strap and pull
outward to desired seat position.
2. Release straps by pushing in the bottom
of the seat adjuster strap and pulling
downwards.
1. To engage brake, push down on the red brake pedal with foot.
To unlock the brake, lift the brake on the rear wheels with foot.
Adjusting backrest
Using the rear brakes
WARNING: On unmade or uneven surfaces all swivels must be locked.
WARNING: Always apply brakes when parking stroller.
Removing the bumper bar
1. Squeeze the buttons on both sides of the bumper bar as per
image. Pull outwards from seat.
Canopy functions
1. Pull the canopy cover forward or push backward.
Assembly / Operating Instructions
Attaching the bumper bar
1. Insert front bumper bar into
openings on the sides of the seat.
Push gently until you hear a click
on both sides.
WARNING: The bumper is only used for the seat unit; do not use it for carrying the
carry cot._
