3. TECHNICAL SPECIFICATIONS
Cooking Hob BIH3302
Cooking Zones 4 Zones
Supply Voltage 220-240 V
Installed Electric Power 6600-7200 W
Product Size L x W x H (mm) 590 x 520 x 55
Building-in Dimensions
A x B (mm)
560 x 490
Please note that Weight and Dimensions are approximate. Since we
continually strive to improve our products we may change specications
and designs without prior notice.
Installation
Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For installation and use, at least 5 cm of space shall be preserved
around the hole.
Please make sure the thickness of the work surface is of at least 30
mm. Please select a heat-resistant work surface material to avoid larger
deformation caused by heat radiation emitted from the hotplate. As
shown below:
