Becken Flex Induction Hob | Placa de Inducción Becken Flex | Placa de Indução Becken Flex
L (mm) W (mm) H (mm) D (mm) A (mm) B (mm) X (mm)
590 520 55 51 560 490 50 mini
Under any circumstances, make sure the induction cooker hob is well
ventilated and the air inlet and outlet are not blocked. Ensure the
induction cooker hob is in good working conditions. As shown below:
Note: The safety distance between the hotplate and the
cupboard above it should be of at least 760 mm.
A (mm) B (mm) C (mm) D E
760 50 mini 20 mini Air intake Air exit
5 mm
Before you install the hob, make sure that
• the work surface is square and level, and no structural members
interfere with space requirements
• the work surface is made of a heat-resistant material
• if the hob is installed above an oven, the oven has a built-in cooling
fan
