Table of Contents
Specifications on page 3
General information on page
4
User interface and navigation on page 8
Operation on page 11
Maintenance on page 17
Troubleshooting on page 18
Replacement parts and accessories on page 18
Specifications
Specification Details
Size range 0.3 µm - 10 µm channels per ISO 14644-1 (FS 209E) industry standard;
HHPC 3+ (0.5 µm) and HHPC 2+: 0.5 µm–5 µm
Number of channels HHPC 6+: Channel 1 fixed at 0.3 µm, and up to five additional channels with
sizes selectable from 0.5, 1.0, 2.0, 5.0 or 10.0 µm.
HHPC 3+ (0.3 µm): Channel 1 fixed at 0.3 µm, and up to two additional
channels with sizes selectable from 0.5, 1.0, 2.0, 5.0 or 10.0 µm.
HHPC 3+ (0.5 µm): Channel 1 fixed at 0.5 µm, and up to two additional
channels with sizes selectable from 1.0, 2.0 or 5.0 µm.
HHPC 2+: Channel 1 fixed at 0.5 µm, and up to one additional channel with
sizes selectable from 1.0, 2.0 or 5.0 µm.
Weight 0.7 kg (1.5 lbs)
Flow rate 2.83 lpm. Get ISO 14644-1 class 5 compliant 0.3 µm samples in a minute.
USB support Simple data export to memory stick or direct connect to PC via USB cable.
No software required.
Ethernet support Access particle data over network with an internet browser such as Windows
Explorer, Safari and Firefox
Display 3.5" High resolution 320 x 240 color
Display configuration User selectable size channels
Display data modes Traditional tabular particle counts or trend graph
Enclosure High-impact polycarbonate ABS
Enclosure rating IP40 Environmental rating. Protected from objects 1 mm in diameter or
larger. Not protected from water.
Dimensions (L x W x D) 272 x 99 x 54 mm (10.7 x 3.9 x 2.1 in.)
Battery duration More than 10 hours with typical use model. Minimum 5.5 hours continuous
sampling.
Battery charging 3.5 hours
Data storage 10,000 records (5,000 records for .xls CFR 21 Part 11 secure files)
Counting efficiency 50% at 0.3 µm; 100% for particles > 0.45 µm (per ISO 21501)
Zero count level 1 count every 5 minutes (per JIS B9921)
Concentration limits 10% at 4,000,000 per cubic foot (per ISO21501)
Count modes Raw counts, N/CF, N/CM, N/L in Cumulative or Differential mode
Security Administrator password controlled (optional)
English 3
