CAUTION: Unbalanced or warped blades can cause damage to the mower and/or
personal injury. Replace damaged blades before operating the mower. Sharpen
both ends of the mower blades equally or until the blade is balanced.
4.04 - Belt Tension
Belt tension control
Check the belt tension (see fig. 21) by applying a force of 12-15 lb. pushing against the
belt halfway between the pulleys. The belt deflection should be between
5
/
16
”-
3
/
8
”.
MAINTENANCE 37 BEFCO
C
YCLONE SUPER-FLEX OPERATOR’S MANUAL
Fig. 21
The belt deflection should be
between 5/16"-3/8".
Fig. 22
1
2
3
1. adjustment bolt
2. gearbox support plate
3. gearbox
