Beghelli SanificaAria 200 Connect - Page 13

7
MAINTENANCE
Before cleaning or maintenance, make sure the device is turned off and disconnected from the power
supply.
CLEANING
Periodically remove the dust, eventually deposited on the external grids, using a brush. When replacing
the Cartridge, remove the dust on the internal deectors.
Note: The residual dust agglomerates in the sanitizing chamber are totally free of bacterial load.
SanicaAria 200 TECHNICAL FEATURES (cod. 26702)
Power supply: 90VAC ÷256 VAC, 50÷60Hz (2m long cable)
Absorption:
- <60W (minimum speed)
- <65W (medium speed)
- <75W (maximum speed)
Standby absorption: < 1.5W
UV-C Lamp: 2 X TC 2G11 24W (total 48W)
UV-C wavelength: 254nm
Flow of treated air:
- 200m³/h at maximum speed
- 130m³/h at medium speed
- 81m³/h at minimum speed
Radiant power UV-C: 14W
Ozone-free UV-C lamp
Cartridge life: 12 months (continuous use). Replacing the cartridge allows you to keep the germicidal performance
of the device in time.
Noise level:
- 38dB(A) at 1 meter (minimum speeda)
- 47dB(A) at 1 meter (medium speed)
- 59dB(A) at 1 meter (maximum speed)
Weight: 13kg (10Kg without bracket)
ON / OFF button and fan speed adjustment (3 speeds)
BLE interface for local control using the SanicaAria Beghelli APP for Android and IOS
Wi-Fi interface for remote control via DOME-E APP for Android and IOS
RADIO TECHNICAL CHARACTERISTICS
Transceiver with Bluetooth
®
Low Energy (BLE) wireless technology
Frequency band: 2,4GHz-2,4835GHz
Power RF: <100mW e.i.r.p.
Transceiver WiFi
Frequency band: 2.400-2.4835GHz
Wi-Fi standard: IEEE 802.11b/g/n (channels 1-14)
Power RF: <100mW e.i.r.p.
Beghelli S.p.A. declares that the radio transceiver devices compliy with European Directive 2014/53/UE.
The full text of the EU Declaration of Conformity of the device is available at:
www.beghelli.it > area tecnica > download
www.beghelli.it/it/area-tecnica/strumenti/download
The devices can be used in a ‘free use’ policy.
