10 EUROPORT MPA100BT/MPA30BT Quick Start Guide 11
(2)
(1)
(9)
(10)
(11)
(4)
(5)
(6)
(8)
(3)
(7)
MPA100BT
MPA30BT
(3)
(4)
(5)
(6)
(8)
(2)
(1)
(9)
(7)
EUROPORT MPA100BT/MPA30BT Controls
(EN) Step 2: Controls
(ES) Paso 2: Controles
(FR) Etape 2 : Réglages
(DE) Schritt 2:
Bedienelemente
(PT) Passo 2: Controles
(EN) Step 2: Controls
(1) INST/MIC IN combo jacks accept in
put signals over XLR balanced, ¼" TRS
balanced,or ¼" TS unbalanced connectors.
Connecting the wireless microphone system
disables the combination jacks.
(2) INPUT LEVEL knobs control the gain for
either the INST/MIC IN jacks or the
wireless microphones.
(3) BLUETOOTH/MP3 LEVEL knob controls the
overall volume for audio streamed into the
unit via Bluetooth.
(4) MP3 audio jack accepts audio from phone or
media player using a ⁄" (3.5 mm) plug.
(5) WIRELESS SYSTEM LEDs indicate wireless
microphone signal input. Connecting the
wireless microphones system disables the
INST/MIC IN combination jacks.
(6) WIRELESS SYSTEM USB input accepts the
BEHRINGER wireless microphone receiver.
(7) MUSIC/SPEECH switch optimizes
equalization for speech when pressed
inward and latched. During music playback,
the button should be left in the un-latched,
outward position for optimum
music equalization.
(8) MAIN LEVEL knob controls the
overall volume.
(9) BATTERY LEVEL LEDs monitor the overall
amount of remaining battery life when the
unit is unplugged from an outlet.
The CHARGE LED lights up when the unit is
plugged into a wall outlet . (Red, yellow and
green LED lit >75%; Red and Yellow LED lit
=50%; Red LED only <25%, needs CHARGE.)
(10) POWER switch turns the unit o and on.
(11) POWER SOURCE jack accepts the included
IEC cable.
NOTE: The connection range between speaker
and Bluetooth streaming device may decrease if
Bluetooth streaming and wireless microphones are
used simultaneously.
Charging the battery
The MPA30BT/MPA100BT ships with a rechargeable,
internal battery that can power continuous audio
playback for up to 20 hours. We recommend that
you fully charge the battery before your rst use.
To charge the battery for the rst time,
follow this procedure:
(1) Set the POWER switch to the “OFF” position.
(2) Connect the unit to an AC power outlet.
The CHARGE LED will light to indicate the
battery is charging.
(3) Keep the unit plugged into AC power until the
red, yellow and green LEDs light to indicate
the battery has been fully charged.
NOTE: The MPA30BT/MPA100BT uses a sealed
lead-acid gel battery, and the battery will slowly
self-discharge when the MPA30BT/MPA100BT is not
in use. Before storing the MPA30BT/MPA100BT for
an extended period, fully charge the battery before
storage, and then charge again
every 3 months.
NOTE: The lead-acid battery needs to be recharged
every 3 months for continued operation.
Please replace the battery if the MPA30BT/
MPA100BT operating time noticeably decreases,
even after a full charge cycle.
