22 EUROPORT MPA200BT Quick Start Guide 23
Menu (Key Press) Sub-Menu Screen Function
MAIN SCREEN Displays level indicators and model name. The left level
indicator shows the level for all inputs, while the right level
indicator shows the output level.
Rotate the ENCODER KNOB to adjust the master volume control.
Press the ENCODER KNOB to enter the main menu.
Displays the following Bluetooth status information:
Bluetooth symbol indicates connection to audio and
remote control device (iPhone*, etc.)
indicates that the remote Live Control app is
connected.
indicates audio streaming is connected.
“M” or “S” below the Bluetooth symbol indicate that
the speaker is linked to another MPA200BT speaker as
Master (left channel) or Slave (right channel)
VOLUME Rotate the ENCODER KNOB to change the output volume.
Process Menu
MODE Selects from 4 equalization presets, depending on function and
music type.
INPUT Sets input mixer gain for analog input A and B, MP3 audio jack,
and Bluetooth.
EQ Allows adjustment of 3-band equalizer with Bass,
Mid and Treble controls.
Setup Menu
BT Lets you pair the speaker with mobile Bluetooth devices and
link to another MPA200BT speaker as Master/Slave.
SETUP Sets front logo illumination, LCD back panel contrast, device
lock and master reset to restore factory settings.
INFO Displays model and  rmware information.
Exit EXIT Returns to main screen.
CHARGING Indicates the battery is charging when the loudspeaker is
plugged in but powered o .
Firmware
Update
Indicates device is updating  rmware from Live Control app
software via Bluetooth.
*iPhone is a trademark of Apple Inc. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks is under license
DSP Menu
Firmware Update via App
Where possible please update your MPA200BT  rmware using the Live Control app.
To update, go to the Settings Page in the app and look for the “CURRENT FIRMWARE” section. The Live Control app will detect the current  rmware version. If a  rmware and
automatically check for updates provided that the remote device has access to the Internet. If a newer  rmware version is available the app will o er to download. For example:
Swipe the update slider toward the right to initiate the  rmware update. The update may take several minutes.
Update progress will be displayed on the app and the MPA200BT speaker’s LCD screen.
Firmware Update Fallback Procedure
In the event that the system cannot be updated using the Live Control app, you may also carry out the update using this fallback procedure:
1. Download the .dfu  le with the new  rmware version to your remote device from the download section of the respective BEHRINGER product page.
2. Prepare the MPA200BT for a Firmware upgrade by following these steps:
a. Power o the speaker.
b. Hold the ENCODER KNOB.
c. Power on the speaker. You will see the following screen:
d. Please select the option “Firmware upgrade” then press the ENCODER KNOB.
e. The MPA200BT is now ready for the  rmware upgrade.
3. On your remote device, select and hold the .dfu  le until a pop up window o ers options for  le transfer.
4. Select the option for sharing via Bluetooth. (NOTE: Some devices need to be paired with the speaker before  le transfer.)
5. Select the MPA200BT speaker for  le sharing via Bluetooth.
6. During the  le transfer, the LCD screen will display the download progress.
7. After the  le transfer is complete, the MPA200BT speaker will automatically restart and return to the usual startup screen.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Behringer EUROPORT MPA200BT and is the answer not in the manual?

Behringer EUROPORT MPA200BT Specifications

General IconGeneral
Amplifier classD
RMS rated power200 W
Wi-FiNo
Microphone inYes
Frequency range2.4 GHz
USB connector typeUSB Type-A
Connectivity technologyWired & Wireless
Microphone connectivityXLR
Number of microphone inputs2
Volume controlDigital
Recommended usageTablet / Smartphone
Mobile operating systems supportedAndroid, iOS
Battery typeBuilt-in
Power source typeAC, Battery
Battery life (max)10 h
AC adapter input voltage100 - 240 V
Display typeLCD
Product type-
Product colorBlack
Product designRectangle
Country of originGermany
Speaker type2-way
Woofer diameter203.2 mm
Number of speakers1
Audio output channels- channels
Weight and Dimensions IconWeight and Dimensions
Height- mm
Weight12100 g
