Dimensional Drawings
16-Channel Digital ULTRANET Distributor
P16-D
Block Diagram
P16-I
INPUT MODULE
P16-M DIGITAL
PERSONAL MIXER
P16-M DIGITAL
PERSONAL MIXER
ULTRANET
OUTPUTS
IEC POWER
CONNECTION
1 2 3 4 5 6 7 8
BUS-POWER SIGNAL
>incoming power signal - ignored
>outgoing power signal - only if P16-D is powered on
16-CHANNEL DIGITAL AUDIO SIGNAL
>incoming audio signal - distributed parallel to 8 outputs
>even if P16-D is powered OFF - audio signal distributed
POWERPLAY 16 P16-D
DIGITAL ULTRANET DISTRIBUTOR
ULTRANET IN
