Behringer S16 - Front and Rear Panel Overview; Front Panel Controls; Rear Panel Connections

Page 3 of 6
Balanced analog
XLR mic inputs
with phantom
power LEDs
Front View
Gain selector
allows metering
and adjustment
of selected input
Display panel with
4-digit readout
for selected input,
AES50 network
activity and
conguration
mode indicators
HA Control
adjusts selected
input signal level
6-tier metering
plus Clip
and Signal
present LED
48 V switch
applies phantom
power to the
selected input
Balanced analog
XLR outputs
Conguration
selection switch
Phones jack
and Monitoring
Level adjustment
control
Rear View
Standard IEC
Power socket and
Power switch
Dedicated ULTRANET
socket connects
to P-16 Personal
Monitoring System
(sold separately)
MIDI I/O sends
data to and from
on-stage devices
USB socket
enables system
updates via PC
AES50 SuperMac
Audio Network
sockets
ADAT optical
outputs sends
signal directly to
outboard devices
S16
Digital Snake I/O
