Behringer T-1 Quick Start Guide

Specications Especicaciones técnicas
16 17Quick Start GuideTUBE CONDENSER MICROPHONE T-1/T-47
T-1 T-47
Transducer type Condenser, 16 mm (0.63")
Polar pattern Cardioid
Preamplifier Vacuum tube
Output Gold-plated balanced XLR connector
Open circuit sensitivity -40 dBV (0 dBV = 1 V/Pa)
Frequency response 20 Hz - 20 kHz
Level attenuation -20 dB, switchable / -20 dB, conmutable -
Low-cut filter 12 dB/oct. @ 100 Hz (switchable / conmutable)
Max. SPL/SPL (3% THD/DHT @ 1 kHz) 130 dB
Dynamic range 110 dB
Nominal impedance Approx. 200Ω
Load impedance >1 kΩ
Supply voltage
Adapter BEHRINGER PSU-T
Mains Voltage
100-120 V~, 50/60 Hz T 160 mA L 250 V
220-230 V~, 50/60 Hz T 80 mA L 250 V
Power Consumption 12 W
Mains connector Standard IEC receptacle
Physical/Weight
Dimensions Ø shaft: 2.7", length: 8.3"
Weight (net)
Approx. 1.7 lbs / approx. 0.77 kg
T-1 T-47
Tipo de transductor Condensador, 16 mm
Patrón polar Cardioide
Preamplificador Válvula (12AX7)
Salida (PSU-T) Conector XLR balanceado y chapado en oro
Sensibilidad de circuito abierto -40 dBV (0 dBV = 1 V/Pa)
Respuesta de frecuencia 20 Hz - 20 kHz
Atenuación de nivel -20 dB, switchable / -20 dB, conmutable -
Filtro de corte de graves 12 dB/oct. @ 100 Hz (switchable / conmutable)
Max. SPL/SPL (3% THD/DHT @ 1 kHz) 130 dB
Rango dinámico 110 dB
Impedancia nominal Approx. 200Ω
Impedancia de carga >1 kΩ
Alimentación
Adaptador BEHRINGER PSU-T
Voltaje
100-120 V~, 50/60 Hz T 160 mA L 250 V
220-230 V~, 50/60 Hz T 80 mA L 250 V
Consumo 12 W
Conector de corriente Receptáculo IEC standard
Dimensiones /Peso
Dimensiones Diámetro / Ø Corps : 68 mm, longitud / longueur : 211 mm
Peso (neto)
Approx. 1,7 lbs / approx. 0,77 kg
Cardoid pattern Frequency response Patrón cardiode Respuesta de frecuencia

Behringer T-1 Specifications

Physical Dimensions

transducer type	16 mm (0.63")
dimensions	shaft: 68 mm, length: 211 mm
weight	0.77 kg

Audio Specifications

frequency response	20 Hz to 20 kHz
open circuit sensitivity	-40 dBV (0 dBV = 1 V/Pa)
max SPL	130 dB

Electrical Specifications

nominal impedance	approx. 200 Ω
supply voltage adapter	BEHRINGER PSU-T
mains voltage	100-120 V~, 50/60 Hz T 250 mA H 250 V / 220-230 V~, 50/60 Hz T 125 mA H 250 V
