Behringer ULTRALINK ULM100USB Quick Setup Guide

ULM100USB Controls
ULM100USB Controls
1. POWER/STATUS LED
2. ▼ VOLUME Button (Mute/volume down)
3. ▲ VOLUME Button (Power on/unmute/volume up)
4. USB connector
5. Wireless Link Status LED
ULM100USB Getting Started
1. Press and hold the ▲ button to power on the ULM100M
wireless microphone.
2. Connect the ULM100R wireless receiver to the wireless only
USB connector on the wireless enabled device or to a USB port
on a computer. The ULM wireless microphone will sync to the
receiver automatically.
3. Use the ▼ and ▲ buttons on the ULM100M wireless
microphone to adjust the volume.
4. Press and hold the ▼ button to mute the volume of the
ULM100M wireless microphone.
5. Press and hold the ▲ button to unmute the volume of the
ULM100M wireless microphone.
6. Disconnect the ULM100R wireless receiver. The ULM100M wireless
microphone will power o when no wireless signal is detected
for more than 1 minute. To ensure longer battery life, unplug the
ULM100R wireless receiver after use.
Specication
RF output +17 dBm (50 mW)
Working range 120 m maximum (Lineof
Sight)
Dynamic range > 67 dB
Frequency response 20 Hz – 15 kHz
(Wireless Link)
Sampling rate 31.25 kHz
Audio coding Pulse-coded modulation
(PCM)
RF channel 2.4 GHz ISM band (2417 -
2471 MHz), 19channels
Latency 9 ms
Power supply current 160 mA @ +2.7 VDC,
(microphone) 140 mA @ +3 VDC
Power supply current 100 mA @ +5 VDC
(USB receiver)
Dimensions (W x D x H) 45 x 45 x 245 mm
(1.8 x 1.8 x 9.6")
Weight 0.2 kg (0.4 lbs)
(1)
(2) (3)
(5)(4)
Model: ULM100R
Type of product: Wireless Microphone
Model: ULM100M
