Behringer XENYX Q802USB Brochure

Page 7 of 12
IEC power socket Phantom Power
switch
Main Outputs,
¼" TS unbalanced
Main Inserts, ¼"
TS unbalanced
Control Room Out,
¼" TS unbalanced
FX Footswitch jack Sub 1-8 Outputs,
¼" TS unbalanced
Power switch
Main Outputs,
XLR balanced
Aux Sends
1-4, ¼" TS
unbalanced
FX Out, ¼"
TS unbalanced
Channel 1-8
Direct Outputs,
¼" TS unbalanced
Stereo Aux
Returns 1-4
USB/Audio
Interface port
XENYX QX2442USB Rear Panel
XENYX QX1204USB/Q1204USB Front Panel
Onboard FX processor
(not on Q1204USB),
32 editable presets,
three parameter controls
plus TAP function
Stereo Aux
Sends 1 & 2
Phones/CTRL RM
source mixing matrix
VU meter
mode switch
Alt 3-4 faders
Stereo Aux
Returns 1 & 2
Phones/CTRL RM
level control
8-tier VU meter with
+48 V and Power LEDs
Main Mix faders
XENYX QX2442USB/QX2222USB/
QX1832USB/QX1622USB/
QX1222USB/QX1204USB/
Q1204USB/QX1202USB/
Q1202USB/QX1002USB/
Q1002USB/Q802USB/Q502USB

Behringer XENYX Q802USB Specifications

General

Channels quantity	8 channels
Digital sound processing	- bit
DJ mixer	Yes
Video capability	No

Weight and Dimensions

Depth	248 mm
Width	195 mm
Height	50 mm
Weight	1100 g
