Introduction
The terminal is an operator panel in a family of terminals developed to satisfy the demands
of human-machine communication. The built-in functions in the terminal include the pos-
sibility to display and control text, dynamic indication, alarm, recipe handling and time
channels.
The terminals have, for the most part, an object-oriented way of working, which makes
them easy to use. The terminal can be programmed directly from the terminal or from a
personal computer with the software package E-Designer for Windows. Hereafter, the
product E-Designer is referred to as the PC software. The developed project is transferred
to the terminal and stored in the terminal.
Switch between Programming mode, PROG, and Run-time mode, RUN, by pressing the
keys according to the following table simultaneously.
For more detailed information please see the manual for the terminal.
Terminal Key combination
E50 [F1] + [F4]
E100, E150
[¬]
+
[ENTER]
E200, E300,
E600, E700,
E900
[¬]
+
[MAIN]
E610, E615,
E910
The switch on the back/side of the terminal in position number 4.
RUN=position 0
E710 [F1] + [F2] + [F4]
