BeiJer E710 - Terminal Installation; Power Supply Requirements; Cable Selection Guide

GB
7-5
Installation
Voltage requirement
Cable table
Name
Continental
Europe
GB USA Rest of the world
Cable 1 MAC-PC-CAB-R2/
CAB5
MAC-PROG/9-CAB/
CAB5
MTA-PROG-
C/CAB5
MAC-PROG/9-CAB/
CAB5
Cable 2 CAB6 CAB6 CAB6 CAB6
Ground
CAUTION!
Do not apply reverse
voltage, it can cause
permanent damage.
0 V
+24 V
E200
E700
E710
0 V
+5 V DC
E100
E50
+5 V DC
E300
E600
E150
Ground
0 V
+24 V
E610
E615
E900T/E900VT/E910T
E900TD
E910TD
100-240 VAC
E615T
