A-5
Technical data for E700 and E710
Supply
voltage
+24 V DC (20-30 V DC) 3-pin jack connection block.
CE: The power supply must conform with the requirements for SELV or
PELV according to IEC 950 or IEC 742.
UL: The power supply must conform with the requirements for class 2
power supplies.
Fuse
1 AT, Littelfuse R452 001 (Nano
2
SMF Slo-Blo) or 800 mAT, 5 x 20 mm.
Ambient tem-
perature
0° to +50°C
Storage tem-
perature
-20° to +70°C
Relative
humidity
Max 85% non-condensed.
EMC tests on
the terminal
The terminal conforms with the essential protection requirements in article
four of the directive 89/336/EEC. Noise tested according to: EN50081-1
emission and EN61000-6-2 immunity.
UL approvals UL 508, UL 1604 (Class I Div 2)
DNV approval Det Norske Veritas type
approval certificate. Location
classes: Temperature A,
Humidity B, Vibration A,
Enclosure C (panel front
only).
–––
MTBF (Mean
time between
failure) (h)
104 322 61 368 92 578 73 458 –
Parameter E700 E710
Front panel, WxHxD, mm 276 x 198 x 5.7 211,5 x 198 x 5.7
Mounting depth, mm Excl. D-sub 87
Incl. D-sub 110
Panel cut out, see drawing S3-02412 S4-02513
Front panel seal IP 65, NEMA 4, NEMA 4X (Indoor use only)
Rear panel seal IP 20
Parameter E300 E600 E610 E615 E615T
