A-6
Keyboard material/
Front panel
Membrane keyboard with
polyester snap discs. Over-
lay film of Autotex F207 with
print on reverse side. 1 mil-
lion operations. See Appen-
dix D.
Autoflex EB A180 or Polyes-
ter on glass and Autotext
F207.
Touch screen. 1 million
operations.
See Appendix D.
Reverse side material Yellow-chromated steel plate
Weight, excl. D-sub 1.7 kg
Serial port RS422 25-pin D-sub contact, chassis mounted female with stand-
ard locking screws 4-40 UNC.
Serial port RS232C 9-pin D-sub contact, chassis mounted male with standard
locking screws 4-40 UNC.
Expansion slots 2 2
Flash memory for application 400 kb 400 kb
Real time clock ±10 PPM + error because of ambient temperature and
supply voltage. Total max error 1 min/month = 12 min/year.
Minimum life: 10 years of the battery for the real time
clock.
Current consumption at
rated voltage
Without load: 300 mA
Max load: 550 mA
Display LCD (liquid crystal display),
320x240 pixel, 256 colors,
graphic and text. Back light:
lifetime 25000h at the ambi-
ent temperature of +25°C.
CFL.
LCD (liquid crystal display),
320x240 pixel, 256 colors,
graphic and text. Back light
lifetime: 25000 h at the
ambient temperature of
+25°C.
Touch screen. CFL.
Active area of display, WxH,
mm
115.2 x 86.4 115.2 x 86.4
Contrast setting Programmable
Supply voltage +24 V DC (20-30 V DC) 3-pin jack connection block.
CE: The power supply must conform with the requirements
for SELV or PELV according to IEC 950 or IEC 742.
UL: The power supply must conform with the requirements
for class 2 power supplies.
Fuse
1 AT, Littelfuse R452 001 (Nano
2
SMF Slo-Blo) or 800
mAT, 5 x 20 mm.
Ambient temperature 0° to +50°C
Storage temperature -20° to +70°C
Parameter E700 E710
